MEDEA Programming Manual
109
8.2 Navigating the menus
The following buttons and arrows are used to navigate the menus.
Button
or arrow
Function
MENU
Accesses the main menu
OK
Accesses the submenu
ESC
Goes to the higher menu
▼ ▲
Scrolls menu items on the same level
► ◄
Scrolls through the possible options for the menu item
Table 14 - Menu navigation buttons
8.3 Data entry and selection
8.3.1 Entering characters with the keypad
The keypad can be used to enter alphanumeric characters and symbols when necessary to configure a
parameter. Each button allows the cyclic selection of several characters and symbols. Pressing the ▲
button switches between upper and lower case characters. The following table shows the characters and
symbols associated with each button.
Button
Upper case
Lower case
1
1 . İ , ; - ! ? # *
1 . İ , ; - ! ? # *
2
AB C 2
a b c 2
3
D E F 3
d e f 3
4
G H I 4
g h i 4
5
J K L 5
j k l 5
6
M N O 6
m n o 6
7
P Q R S 7
p q r s 7
8
T U V8
t u v 8
9
W X Y Z 9
w x y z 9
0
<whitespace> _ 0
<whitespace> _ 0
Table 15 - Buttons and associated characters
Press ▼ to delete the last character.
8.4 Menu structure
The menu structures are shown on following pages, starting from the main menu.
References to submenus or instructions for use are provided for each menu, if applicable. In addition,
there is a brief description of what it does and an indication of who can access a given menu item (M =
Master, U = User, T = Installer, R = Technical Manager) and whether the menu can be accessed when
the system is armed.
