8.6 System Status menu
This shows the status of all enabled sectors of the system. For systems with more than 16 sectors, the ▲
and ▼ buttons switch between the first 16 sectors and the second 16 sectors and vice versa.
Available for Master, User.
It is accessed through the Main menu → SYSTEM STATUS menu.
Use the ► and ◄ buttons to move between the enabled sectors.
For each sector are shown:
• the number (SE01, SE02 ...);
• the custom description, which scrolls if too long;
• The status is indicated by a blinking square (□ = sector disarmed, ■ = sector armed, O = sector
disarmed with open inputs);
Use the ▲ and ▼ buttons to change the status. Click on OK to confirm.
IMPORTANT! If open inputs or faults are present, acknowledge with OK or ignore with ON.
8.7 Open Input/Tamper menu
This shows whether there are open or tamper inputs.
Available for Master, Installer, User.
It is accessed through the Main menu → OPEN/TAMPER menu.
If there are no open inputs, the display shows
If inputs are opened, the list is updated in real time.
If there are open inputs on the display appears in continuous cycle
followed by the list of individual open inputs displayed in the format
where Inxxx is the logical identifier of the input followed by its custom description.
