MEDEA Programming Manual
53
The following table shows the behaviour of the different activation modes:
Status of sector
inputs upon arming
Standard
Auto-inhibit
Activation-lock
No open input
Arm sector
Arm sector
Arm sector
1 or more open inputs
(up to 70% of the total)
Arm sector + alarm
Arm sector +
inhibit open inputs
Sector not armed
More than 70% of
inputs open
Arm sector + alarm
Arm sector + alarm
Sector not armed
Table 12 - Arming behaviour of sectors
Double-click on the sector line to open a pop-up window that can be used to enable and disable the sector,
add an identification description (e.g. perimeter protection, garage etc.) and configure the Arming Mode.
The text entered in Description is used to generate the voice messages. Use only alphabetic characters,
including accented characters, numbers, and spaces.
Click on the Save button to save the changes, the Close button to close the window and not save the
changes.
The following buttons (some are enabled only by highlighting a sector of the table) are shown below:
• Modify: This can be used to edit the parameters of the sector highlighted in the table.
• CSV: This can be used to export the sectors table to a “.csv” file, which can be opened with a
spreadsheet.
• PDF: This can be used to export the sectors table to a PDF file.
The < and > buttons at the bottom right are used to navigate between the pages of the sectors, if their
number is greater than the number that can be displayed in a single screen.
