Boot for the Fibre Channel Protocol User Manual P010096-02A Rev. A
7. Configure EFIBoot via UEFI HII (Human Interface Infrastructure) in a UEFI 2.1 System
Reset Emulex Adapters to Default Values
101
Reset Emulex Adapters to Default Values
The EFI utility enables you to clear the NVRAM target list and set all boot device
WWNNs back to 0.
These defaults are listed in Table 7-1.
To set Emulex adapters to their default settings:
1. From the Adapter Selection screen, select the adapter whose default settings you
want to change and press <Enter>.
Table 7-1 Adapter Defaults
Parameter Default Valid Values
Enable/Disable BIOS Disabled Enabled
Disabled
ALPA Value 0x00 Fibre See ALPA reference table
PLOGI Retry Timer Disabled Disabled
50 msec
100 msec
200 msec
Boot Target Scan Boot path from
NVRAM targets
Boot path from NVRAM targets
Boot path discovered targets
Do not create boot path
Max LUNs Setting 256 0–4096
Topology Auto (start FC-AL) Auto (start FC-AL)
Point-to-Point
Auto (start Point-to-Point)
FC-AL
Delay Device Discovery 0000 0000–0255
Link Speed 0 (Auto-select) <0> = Auto Select (the adapter’s speed is
selected automatically based on its
model).
<1> = 1 Gb/s
<2> = 2 Gb/s
<4> = 4 Gb/s
<8> = 8 Gb/s
<16> = 16 Gb/s
