TS-10 Musician’s Manual Section 7 — Effect Parameters
13
For a complete description of the SENDS parameters, refer to the DDL+PHLANGR+REV
algorithm found earlier in this section.
For a complete description of the PARAM EQ parameters, refer to the PARAM
EQ+CHORUS+REV algorithm found earlier in this section.
For a complete description of the PHLANGR parameters, refer to the DDL+PHLANGR+REV
algorithm found earlier in this section.
For a complete description of the remaining Reverb parameters, refer to the
DDL+CHORUS+REV algorithm found earlier in this section.
14 ENV VCF+PHLANGR+REV
This parallel effect combines a voltage control filter with a phlanger (a combination phaser and
flanger effect) and a reverb. The second sub-page (not user-programmable) shows how this
parallel effect is routed:
• Voices assigned to FX1 (and panned left) are sent to Effect A (ENV VCF)
• Voices assigned to FX1 (and panned right) are sent to Effect B (PHLANGR)
• Voices assigned to FX2 are sent to the reverb (REV)
For a complete description of the SENDS parameters, refer to the DDL+PHLANGR+REV
algorithm found earlier in this section.
For a complete description of the ENV VCF parameters, refer to the ENV VCF+CHORUS+REV
algorithm found earlier in this section.
For a complete description of the PHLANGR parameters, refer to the DDL+PHLANGR+REV
algorithm found earlier in this section.
For a complete description of the remaining Reverb parameters, refer to the
DDL+CHORUS+REV algorithm found earlier in this section.
15 DDL+ROTOSPKR+REV
This parallel effect combines a digital delay with a rotary speaker effect and a reverb. The second
sub-page (not user-programmable) shows how this effect is routed:
• Voices assigned to FX1 (and panned left) are sent to Effect A (DDL)
• Voices assigned to FX1 (and panned right) are sent to Effect B (ROTOSPKR)
• Voices assigned to FX2 are sent to the reverb (REV)
SENDS A- -B Range: 00 to 99
Controls the amount of Effect A (DDL) being sent into Effect B (the rotary speaker). A setting of
99 would yield a serial connection between Effect A and the rotary speaker effect for voices sent
to FX1 and panned hard left (on the Output page).
B- -REVRB Range: 00 to 99
Controls the amount of Effect B (ROTSPKR) being sent into the reverb. This would allow you to
add reverb to voices assigned to FX1 and panned hard right. A setting of 99 would yield a serial
connection between the ROTSPKR and the reverb for voices sent to FX1 and panned hard right
(on the Output page).
