TS-12 Musician’s Manual Section 2 — System Page Parameters
9
Using the U1-Programs Pitch-Tables
Note: You will need the TSD-100 floppy disk that was included with the TS-10 to complete the
following exercise. This disk contains two files of pitch-tables. They are stored as 60-
PROGRAMS file types. The first pitch-table file is called HIST PTABLS and contains five
different Historical pitch-tables with twelve root key versions of each scale. The second file is
called ETH/MOD PTS and contains a variety of Ethnic and Modern pitch-tables:
• Insert the TSD-100 floppy disk into the disk drive and press the Storage button twice.
Tip: Pressing the Storage button twice will automatically take you to the Disk Load Page.
• Press the Up or Down Arrow button until the display reads TYPE=
60-PROGRAMS
.
• Press the upper left soft button above the words LOAD FILE=__________. Using the Up or
Down Arrow button, find the file named
ETH/MOD PTS
.
• Press the bottom middle soft button beneath the words BANKSET U0, and press the Up
Arrow button once so the display reads BANKSET U1.
• Press the upper right soft button above the word *YES*. This will load 60 new pitch-table
Programs into User RAM BankSet 1.
When the file has been loaded, the display will show DISK COMMAND COMPLETED.
• Press the System button four times until the display reads SYSTEM PITCH-TABLE=
<last
selected pitch-table>
. Press the Up or Down Arrow button to set this value to PITCH-
TABLE=
U1-PROGRAMS.
• Press the Sounds button and select a sound of your choice from any BankSet other than
BankSet U1.
• While holding down the BankSet button, press the Bank 1 button, then release both buttons.
You have now selected User RAM BankSet U1.
Note: At this point when you select locations in BankSet U1, you will be selecting from 60 pitch-tables
instead of 60 Programs. The Programs that were originally stored in BankSet U1 have been
replaced by the newly loaded pitch-table file.
• Press the Bank 0 button and then press the upper left soft button. Play the keyboard. This
selects the first of the 60 pitch-tables that are instantaneously available.
Try the other pitch-tables in Bank 0 by pressing the other soft buttons. Continue by selecting
pitch-tables in Banks 1 through 9. Each Bank contains six pitch-tables.
Using the above procedure, you can load the file named HIST PTABLS to try more pitch-tables.
Loading a full set of 60 pitch-tables into the TS-10 internal memory in this way gives you the
ability to select a variety of keyboard tunings in real-time while in the middle of a performance!
Pitch-tables can even be remotely selected via incoming MIDI Program Changes.
