TS-10 Musician’s Manual Section 9 — Program Parameters
33
Wave-List Editor Parameters
The following parameters are only available when OPTION=WAVE-LIST on the Program Control
Page. To access the Wave-List Editor parameters for a program that does not contain a Wave-List:
1) Press the Program Control button.
2) Select the OPTIONS parameter by pressing its soft button.
3) Press the Up Arrow button.
4) Select WAVE-LIST on the bottom of the display by pressing its soft button.
5) Press either of the soft buttons beneath EDIT WAVE-LIST.
The Wave-List Editor parameters are:
Wave Name and ClassCurrent Wave-List Step
Determines the
Wave Start time
Press to go to
Time sub-page
Press to go to
Pitch sub-page
STEP Range: 01 to 16
Defines which of the 16 steps within the Wave-List will be edited.
Wave Name and Class Range: All ROM waves
Defines which of the internal ROM waves will be used in the currently selected step.
START Range: 00 to 99
Determines the starting point within the internal ROM wave. This can be used to eliminate the
attack portion of a wave to create a smoother transition between waves.
*TIME*
Pressing this soft button will reveal the following screen:
STEP Range: 01 to 16
Selects the wave step to be edited, followed by the Wave Name for the current Step (read-only).
DUR Range: 00000 to 60000 (0 to 60 sec)
Selects the total length of time that the selected wave step will play. The duration is defined in 12
millisecond increments.
VOL Range: -50 to +14 dB
Sets the volume for the selected wave step.
To Next Page
