ENSONIQ TS-10 User Manual

TS-10 Musician’s Manual Section 15 — Sampled Sound Parameters
13
amplitude
frequency0
freq.
cutoff
18 db / oct
Filter 1 = 3 pole / Low-pass
amplitude
frequency0
freq.
cutoff
24 db / oct
4 pole / Low-pass
amplitude
frequency0
freq.
cutoff
6 db / oct
Filter 2 = 1 pole / Low-pass
amplitude
frequency0
freq.
cutoff #2
freq.
cutoff #1
6 db / oct
24 db / oct
4 pole / Low-pass
+ = Or
(when F1 and F2
are tuned to the
same frequency)
+
=
amplitude
frequency0
freq.
cutoff
12 db / oct amplitude
frequency0
freq.
cutoff
12 db / oct
Filter 2 = 2 pole / Low-pass
Filter 1 = 2 pole / Low-pass
amplitude
frequency0
24 db / oct
freq.
cutoff
4 pole / Low-pass
(when F1 & 2 are
tuned to the same
freq.)
amplitude
frequency0
freq.
cutoff #1
freq.
cutoff #2
12 db / oct
24 db / oct
4 pole / Low-pass
Or
F F
Filter 1 = 3/LP Filter 2 = 1/HP Bandpass
+ =
+
=
F F
BandpassFilter 1 = 2 pole / Low-pass Filter 2 = 2 pole / High-pass
