C8 Maintenance 3. Covers
C Series Maintenance Manual Rev.2 197
Cable backward model
Connector
plate
Connector sub plate
Arm #4 side cover
Arm #3 cover
Arm #1
center cover
Base cover
Arm #3
maintenance
cover
Arm #4
D-sub attachment
Arm #4 side cover
Arm #2
side cover
Arm #1
side cover
Arm #2 side cover
Arm #1 side cover
Arm #4
maintenance
cover
Arm #1
maintenance cover
(Figure: C8-A1401* (C8XL))
Fan
C8-A1401* (C8XL) only
Cable downward model
Connector
plate
Connector sub plate
Fan
C8-A1401*B*
(C8XL) only
(Figure: C8-A1401*B* (C8XL))
Base cover
