C8 Maintenance 8. Joint #4
C Series Maintenance Manual Rev.2 351
8.2 Joint #4 - Replacing the Reduction Gear Unit
Name Qty. Note
Maintenance
Parts
Reduction
gear unit
(Joint #4)
C8-A701*** (C8)
C8-A1401*** (C8XL)
1
1674609
C8-A901*** (C8L)
1
1675434
Belt tensile jig*
1
1674582
Tools
Hexagonal
wrench
width across flats: 2.5 mm
1
For M3 hexagon socket head cap bolts
width across flats: 3 mm
1
For M4 hexagon socket head cap bolts
width across flats: 4 mm
1
For M5 hexagon socket head cap bolts
width across flats: 5 mm
1
For M6 hexagon socket head cap bolts
Cross-point screwdriver (#2)
1
For cross recessed head screws
Torque wrench
1
For tightening torque control
Belt tension meter
1
Refer: Unitta U-505
* The belt tensile jig is an assembly jig. Use the jig when adjusting belt tension.
The brake is mounted on each joint to prevent the arm from lowering due to its own weight while the Controller
power is OFF or the motor is OFF status. The brake does not work during replacement. Be careful when
performing maintenance work.
