C8 Maintenance 7. Joint #3
328 C Series Maintenance Manual Rev.2
7.1 Joint #3 - Replacing the Motor
Name
Qty.
Note
Maintenance
Parts
AC servo motor 400 W 1 2168684
Belt tensile jig*
1
1674582
Tools
Hexagonal
wrench
width across flats: 2.5 mm
1
For M5 hexagon socket set screws
width across flats: 3 mm
1
For M4 hexagon socket head cap bolts
width across flats: 4 mm
1
For M5 hexagon socket head cap bolts
Cross-point screwdriver (#2)
1
For cross recessed head screws
Torque wrench
1
For tightening torque control
Feeler gauge (0.5 mm)
2
For pulley position adjustment
Belt tension meter
1
Refer: Unitta U-505
Cloth (cushioning)
1
For pressing arms
* The belt tensile jig is an assembly jig. Use the jig when adjusting belt tension.
The brake is mounted on each joint to prevent the arm from lowering due to its own weight while the
Controller power is OFF or the motor is OFF status. The brake does not work during replacement.
Be careful when performing maintenance work.
When removing the Joint #3 motor, tilt the Arm #2 and press it against the Arm #2.
Reference: C8 Maintenance: 7.1 Joint #3 - Replacing the Motor, Removal step (2)
When pressing the arm, put a piece of cloth or a similar material between the arms to avoid contacting each
other. This protects the arm surfaces from scratching and paint peeling off.
