C8 Maintenance 5. Joint #1
C Series Maintenance Manual Rev.2 277
3-4 Wrap the wire tie around the motor.
3-5 Tighten the wire tie to hold the heat radiation sheet firmly.
Make sure that the heat radiation sheet sticks out of the heat radiation
block.
Do not tighten the wire tie too much. It may result in cable
breakage.
NOTE
