Setup & Operation 14. Option Slots

110 RC700 / RC700-A Rev.23

(9) Connect “Cable2 CN1”.

Use a cross-point screwdriver to fasten the connector (CN1).

(10) Mount the Top Panel. (Mounting screw ×6)

(11) Connect “Cable2 CN4” to the IMM.

(12) Connect the power plug. Turn ON the Controller and make sure that the Controller

starts properly without any vibration or abnormal noise.

Default Chapter7
