B-12 Product Specifications
Interface Specifications
Your printer is equipped with an 8-bit parallel interface and a USB
interface.
Parallel interface
The built-in parallel interface has the following characteristics.
Forward channel
Reverse channel
Data format 8-bit parallel, IEEE-1284 compatibility mode,
IEEE-1284 ECP mode
Synchronization See the IEEE-1284 specification
Handshake timing See the IEEE-1284 specification
Signal level IEEE-1284 Level 1 device
Connector 57-30360 Amphenol connector or equivalent
Transmission mode IEEE-1284 Nibble mode,
IEEE-1284 ECP mode
Adaptable connector 57-30360 Amphenol connector or equivalent
Synchronization See the IEEE-1284 specification
Handshaking See the IEEE-1284 specification
Signal level IEEE-1284 Level 1 device
Data transmission
timing
See the IEEE-1284 specification
