ER1 User Guide A-5
Getting to Know the Parts
Struts
The Struts are used to attach the laptop cradle to the caster wheel. There
are two struts in your kit, one right and one left.
T-nuts
T-nuts are used with the Allen screws to secure such things as the struts.
All the T-nuts you will need are already attached to the subassemblies.
Thumbnuts
The thumbnuts are paired with the Philips screws. Together, they secure
joints in the robot. There are three thumbnuts in your kit.
U-clips
The U-clips are used to connect the beams together. Remember to use the
sets screws to tighten the connections.
U-clips, like the rest of the plastic connectors, come as halves. Press the
halves together to create a whole U-clip. There are eighteen U-clip halves
in your kit.
USB Cord
The USB cord connect the Robot Control Module to your laptop. There is
1 USB cord in your kit.
