SMP 300 Series • Remote Communication and Control 119
Command Function SIS Command
(Host to Device)
Response
(Device to Host)
Additional Description
IP Setup Commands
Set date / time E
MM/DD/YY-
HH:MM:SS CT
}
Ipt
•
X1#
] Set the date and time.
View date / time E
CT
} X1#
] View the date and time.
Set time zone
Example:
E X1$
* TZON
}
E
PST * TZON
}
Tzon
•
X1$
*
X1%
]
Tzon
• PST*(UTC-08:00/UTC-07:00)•
]
View time zone E
TZON
}
Verbose mode 2/3
Example:
X1$
*
X1%
]
Tzon
•
X1$
*
X1%
]
PST*(UTC-08:00/UTC-07:00) •
]
View all time zones E
* TZON
} X1$
*
X1%
]
...
X1$
*
X1%
]]
Repeats for all time zones
Verbose mode 2/3 adds Tzon
•
to beginning of string
Set DHCP on E
1DH
}
Idh1
] Sets DHCP to on.
Set DHCP off E
0DH
}
Idh0
] Sets DHCP to off.
View DHCP mode
E
DH
} X(
]
0=DHCP off (default)
1=DHCP on.
KEY:
X(
= On/off 0 = Disabled/off (default), 1 = Enabled/on
X1#
= Local date/time Set: MM/DD/YY‑HH:MM:SS
Read: day of week, date, month, year HH:MM:SS (for instance; Fri, 21 Jun 2002 10:54:00)
X1$
= Time zone Acronym (2 to 6 letters) Example: PST for Pacific Standard Time
X1%
= Time zone offset GMT offset value (– 12:00 to 14:00) representing hours and minutes (HH:MM) local time is offset
from GMT time and includes the time zone name. Example: PST*(UTC-08:00) Pacific Time
Set IP address, subnet
mask, gateway
E
1*
X1^
*
X1&
*
X1^
CISG
}
Cisg1*IP/subnet bits*gateway
]
NOTE: The CISG command resets the network immediately without the need for a BOOT command.
View IP address, subnet
mask, gateway
E
1CISG
}
Example:
IP/subnet bits*gateway
]
192.168.254.254/16*0.0.0.0
]
Set IP address E X1^
CI
}
Ipi
•
X1^
]
View IP address E
CI
} X1^
]
View hardware MAC
address
E
CH
}
Verbose mode 2/3
X1*
]
Iph
•
X1*
]
View the hardware MAC
address of the unit.
Set subnet mask
E X1&
CS
}
Ips
•
X1&
]
View subnet mask E
CS
} X1&
]
Set gateway IP address E X1^
CG
}
Ipg
•
X1^
] Set the gateway IP address.
View gateway IP
address
E
CG
} X1^
] View the gateway IP address.
Set DNS server IP
address
E X1^
DI
}
Ipd
•
X1^
] Set the DNS server IP address
(default: 0.0.0.0).
View DNS server IP
address
E
DI
} X1^
] View the DNS server IPaddress.
KEY:
X1^
= IP Address Default IP address: 192.168.254.254
Default Gateway: 0.0.0.0
Default DNS: 0.0.0.0
X1&
= Subnet Mask Default: 255.255.0.0
X1*
= Hardware MAC address 00-05-A6-
xx
-
xx
-
xx
