Trendline 3
program automatically adds the .csv ("comma separated variables") extension.
Click on OK to export the data.
Below is a description of the contents of the export file depending on the type of
measuring point.
Measuring point from a Cm configuration
If you export a measuring point from a CM configuration, the Trendline software
saves a general export file with details of the configuration and other files with the
time signals.
The general export file contains a line for each measurement containing the
following:
Heading
Contents
idx
Measurement identification number.
State
Alarm Status: 0 – no alarm, 1 – pre-alarm, 2 – main alarm
Timestamp
Measurement timestamp.
Velocity
Export file with velocity time signal (the signal is an acceleration signal,
see also "Time signals ").
Acceleration
Export file with the acceleration time signal.
Demodulation
Export file with the demodulation time signal.
Data x
Characteristic value measured
Name x
Name of characteristic value
Type x
Type of characteristic value .
Prealarm x
Pre-alarm threshold in % of the main alarm threshold.
Alarm x
Main alarm threshold.
Measuring point
Name of measuring point
export_timestamp
Export time
Comment
Measuring point comment
used_revolution
The rotational speed input by the user after the measurement. This value
is identical to the rotational speed actually measured until it is changed.
config_revolution_delta
The maximum rotational speed deviation set in the measuring point
configuration
config_revolution
The rotational speed set in the measuring point configuration.
