Trendline 3
press the key combination CTRL+C or click on .
Left-click on the target element and
press CTRL+V or click on .
Deleting elements
When you delete a configuration element, the element is deleted
along with all its sub-elements including data forever!
Right-click on the element and select Delete entry.
Or:
Left-click on the element and press Del.
Or:
Left-click on the element and
click on .
4.3 First steps
4.3.1 Adding a sensor
Before you can set up configurations, you must define the sensors you want to
use. Detector III is delivered with all necessary sensors. They are pre-defined in
the Trendline software.
WARNING
Damage to sensors when continuous operation is activated
If you would like to connect passive sensors to the Detector, the
continuous operation of the sensor must be deactivated to avoid
damaging the sensor.
Proceed as follows to add new sensors:
In the Detector menu click Sensor > Add.
In Sensor type choose from Acceleration, Temperature or Trigger sensor.
In the Name field, enter a name for the sensor, e.g. "IMI 627".
