Click OK to apply the changes or Cancel to discard them.
5.3.9 Using the diagram information bar
Displaying the diagram information bar of the viewer
The diagram information bar contains additional information on the diagram
displayed and outputs the relevant characteristic measured values in tabular form
depending on the cursor selected. There are a number of ways in which the
diagram information bar can be displayed.
Adjusting the default setting for the diagram information bar display via the
Viewer options
The default setting for the diagram information bar display can be adjusted with
the Viewer options. The settings can be configured individually for each diagram
type (FFT, time signal or trend data). This default setting is used when new
diagrams are opened.
1.
Click on the Extras menu.
2.
Select the Options menu item.
The Viewer options dialog opens.
