FIS Viewer
Mark zoom area with mouse
Select one of the zoom tools from the selection list.
Mark a zoom area in the diagram using the right mouse button.
Your selection is marked in the diagram.
Reset zoom
Right click on the diagram if you wish to return to the previous zoom selection.
Or:
If you wish to return to the full view of the diagram hold down the Shift-key and
right click on the diagram
Assign zoom area to other diagrams (Synchronous zoom)
You can assign the zoom area of all diagrams automatically, which have identical
type and base units. Proceed as follows:
If you opened several datasets in the FIS Viewer,
select one of the zoom tools and
click on the diagram type whose zoom area you want to change.
Hold down the Alt-key and span the area with the right mouse button.
The zoom area of all diagrams with identical type and base units will be
assigned.
Reset synchronous zoom
Hold down the Alt-key and right click on the diagram if you wish to return to the
previous zoom selection.
Or:
To reset all by synchronous zoom changed diagrams, press Ctrl+Alt+Space.
5.3.4 Zoom tools
1.
Select one of the zoom tools from the selection list.
2.
Mark a zoom area in the diagram using the right-hand mouse button.
Your selection is marked in the diagram.
3.
Right click on the diagram if you wish to return to the previous zoom selection.
4.
If you wish to return to the full view of the diagram hold the Shift button down
and right click on the diagram.
