Connecting the SplitBox SB 500i R to the system
components
Safety
WARNING!
An electric shock can be fatal.
Before starting the work described below:
▶
Turn the power source mains switch to the "O" position
▶
Disconnect the power source from the mains
▶
Ensure that the power source remains disconnected from the mains until all
work has been completed
CAUTION!
Risk of injury and damage from loose connections.
▶
All cables, leads and hosepacks must be properly secured, undamaged, insu-
lated and adequately dimensioned.
General
NOTE!
Also follow the instructions and information in the documents 42,0410,1946
and 42,0410,2010 when connecting the wirefeeder to the system components.
Connecting the
SplitBox SB 500i
R to the system
components
IMPORTANT! Whenever the torch hosepack is fitted or removed, ensure that the
coupling point is clean and dry. Remove any coolant that has escaped from the
coupling point.
SB 500i R (right variant)
1
100
