Fitting the WF R
obacta Drive t
o a P
AP robot
Fitting the
hosepack to the
WF Robacta
Drive (P
AP)
IMPORT
ANT!
Only fit the drive unit when the power source is swit
ched off
.
C
AUTION!
Danger of property damage due to dirty or wet coupling point.
▶
Whenever the hosepack is fitt
ed or removed, ensur
e that the coupling point
is clean and dry
.
▶
Remov
e any coolant tha
t has escaped from the coupling point.
1
2
3
42,041
1,1315
45,0200,1261
4
111
EN
110
112
