Fronius Pull User Manual

(9) Blanking cover for option 2
(10) Wire infeed
Side view (right variant)
No. Function
(11) Cover
(12) Bushing
(13) Gas test / wire threading con-
trol panel (option)
SB 500i R PAP
control ele-
ments, connec-
tions and mech-
anical compon-
ents
Front Rear
No. Function
(1) (+) - current socket
for connecting the power cable from the interconnecting hosepack
(2) Shielding gas connection
(3) SpeedNet connection
for connecting the SpeedNet cable from the interconnecting hosepack
(4) Blanking cover for option 1
(5) Welding torch connection
(6) Blanking cover for option 3
(7) Blanking cover for option 4
(8) Blanking cover for option 5
71
EN
