General
Safety
WARNING!
Work that is carried out incorrectly can cause serious injury or damage.
▶
The following activities may only be carried out by trained and qualified per-
sonnel.
▶
The Operating Instructions for system components, particularly the chapter
entitled "Safety rules", must be observed.
WARNING!
An electric shock can be fatal.
Before starting the work described below:
▶
Turn the power source mains switch to the "O" position
▶
Disconnect the power source from the mains
▶
Ensure that the power source remains disconnected from the mains until all
work has been completed.
WARNING!
Risk of serious injury and damage from articles being dropped.
For all of the screw connections referred to below:
▶
Check after fitting to ensure they are tight
▶
Check following an unusual operating situation (e.g. crash) to ensure they are
tight
▶
Check regularly to ensure they are tight
Assembly se-
quence, conven-
tional robot
Individual components must be fitted to the robot in the following order:
1.
Robot holder(s) must have already been fitted first
2.
SplitBox
3.
Only for CMT applications and for highly dynamic processes in combination
with a 4-roller unreeling wirefeeder: Wire buffer
4.
CrashBox /i
5.
WF Robacta Drive
6.
Torch hosepack
7.
Interconnecting hosepack
