Connecting the
torch hosepack
to the SplitBox
SB 60i R
IMPORTANT! Whenever the torch hosepack is fitted or removed, ensure that the
coupling point is clean and dry. Remove any coolant that has escaped from the
coupling point.
The connection of the torch hosepack to the SplitBox SB 60i R is illustrated us-
ing the right version of the appliance.
The left version of the appliance should be connected to the torch hosepack the
other way around.
