Fronius Pull - Page 185

MHP 500i RD / W / PAP
Welding current at 10 min/40 °C
M21 (EN 439)
C1 (EN 439)
100 % ED* / 500 A
100 % ED* / 500 A
Wire diameter 0.8 - 1.6 mm
0.032 - 0.063 inch
Lowest cooling capacity in accordance
with standard IEC 60974-2, depend-
ing on the length of the hosepack
Length
550 W 0.915 m (3.00 ft) / 0.925 m ( 3.03 ft.) /
0.945 m (3.1 ft.) / 1.025 m (3.36 ft.) /
1.045 m (3.43 ft.)
600 W 1.075 m (3.53 ft) / 1.105 m (3.63 ft.) /
1.115 m (3.66 ft.) / 1.135 m (3.72 ft.) /
1.165 m (3.82 ft.) / 1.175 m (3.86 ft.) /
1.185 m (3.89 ft.) / 1.205 m (3.95 ft.)
650 W 1.295 m (4.25 ft) / 1.335 m (4.38 ft.) /
1.355 m (4.45 ft.) / 1.385 m (4.54 ft.)
700 W 1.415 m (4.64 ft) / 1.495 m (4.9 ft.) /
1.575 m ( 5.17 ft.)
850 W 1.935 m (6.35 ft) / 1.985 m (6.51 ft.) /
2.585 m (8.48 ft.)
900 W 2.115 m (6.94 ft)
950 W 2.265 m (7.43 ft) / 3.415 m (11.20 ft.)
1000 W 2.385 m (7.82 ft)
Minimum coolant flow Q
min
1 l/min
0.26 gal (US) / min
Minimum coolant pressure p
min
3 bar
43 psi
Maximum coolant pressure p
max
5 bar
72 psi
Voltage measurement (V-Peak) for
mechanically driven welding torches
141 V
The product conforms to the requirements of the IEC 60974-7 standard
* ED = Duty cycle
185
EN
