Furuno FELCOM501 - How to Send a Message in the Unsent Box

5. WEB INTERFACE
5-21
5.6.6 How to send a message in the unsent box
The unsent messages are saved in the unsent box. You can send the message later.
1. Click [SMS] in the menu bar.
2. Click [Unsent] in the sub menu to show the [Unsent] menu.
3. Click the date the message was created to select the message to send.
Detailed information about the message appears.
See the following table for operation information.
Delete the message. 1) Click the [Delete] button.
2) Click the [OK] button.
3) Click [Close] to close the message.
View the previous message
when there are multiple
messages.
Click [W Previous Message].
View the next message
when there are multiple
messages.
Click [Next Message X].
Operation Procedure
Total message count
Total message count
Total message count
Date on which the
message was created.
Recipient’s phone number.
If the recipient is recorded
as a contact, the recipient’s
name also appears here.
