Quick Setup

17 G-TECH / Pro Competition User Guide, Release 3.1 17

Quick Setup

This section will get you up and running as quickly as

possible.

This section must be completed to obtain accurate

results!!!

Note: DO NOT CALIBRATE ACCELEROMETERS or ERASE ACCELEROMETER CALIBERATION 

on G-tech units which were shipped after August 2003. They have already been calibrated in the 

factory. Older G-techs will automatically request calibration. If you are unsure contact tech support.
