G-Tech Pro Competition - Assembling the Bracket; Figure 9: Mounting Bracket Parts

Quick Setup
37 G-TECH / Pro Competition User Guide, Release 3.1 37
Figure 9 shows the different pieces of the G-tech mounting
bracket.
Figure 9: Mounting bracket parts
Assembling the Bracket
Note: Steps 1-3 may already be performed on your mount-
ing bracket at the factory. These steps are provided so that you
can always properly re-assemble your mounting bracket from its
pieces if necessary.
Suction Cup
Suction Cup
Release Tab
Large (Vacuum) Nut
Small
(Tensioning)
Nut
Mounting Bracket
Mounting
Clip
1
Insert the Large Vacuum Nut into the Mounting
Bracket.
