IIDTool
GAP Diagnostic 2019-07-15 All Rights Reserved
User Manual : Version 33, Firmware V3.0
The interpretation of each “status bit” is performed using the following table.
Interpretation of status bits
according to their state
Position
Status bit
Condition If status bit = 1 If status bit = 0
7
MIL Requested (warning
lamp)
A request was made to turn the
warning lamp ON.
No requests were made in
regards to warning lamps.
6
Test not completed in this
cycle
Test or test sequence not comple-
tedforthisfaultduringthiscycle*
Test or test sequence com-
pleted for this fault during this
cycle*
5 Test failed since last clear
Test or test sequence for this fault
has failed at least once since the
last fault clear.
Test or test sequence for this
fault has not failed since the
last fault clear.
4 Test not completed
The sequence of tests for this
fault has not been completed.
The sequence of tests for this
fault was completed.
3 Conrmed
Thefaultpresenceisconrmed
at the time of reading.
The fault presence is not
conrmedatthetimeofrea-
ding.
2 Pending
The test(s) for this fault has failed
in current or previous cycle,
however, other tests will be
recorded.
There are no results pending.
1 Testfailedthiscycle*
The test(s) failed during this
cycle.Notethatitisnotconr-
med.
The test did not fail.
0 Test failed
Test(s) failed in this or previous
cycle(s).
Test(s) did not failed in this or
previous cycle(s).
Table 24. Interpretation of each “status bit”
*1cycle=forexample,startingandstoppingtheengine.Variesdependingonthefault.
Note : Be aware that a failed test is not necessarily a fault conrmation, because some faults are pro-
grammed to be conrmed if the test fails a number of times (eg. 5 tests). Then a fault is “intermittent”.
The 8 bits do not necessarily apply to all ECUs and faults due to their vocation. In these cases, Status
Bits “not applicable” will be set at any time to “1” and can bring confusion when interpreting faults. For
this reason, applying a lter is recommended. (see section 4.3.2).
