GE Power Management 745 Transformer Management Relay 1-7
1 PRODUCT OVERVIEW 1.2 TECHNICAL SPECIFICATIONS
1
PHASE / NEUTRAL / GROUND / NEGATIVE SEQUENCE TIME OVERCURRENT
Pickup Level: 0.05 to 20.00 in steps of 0.01 x CT
Dropout Level: 97 to 98% of Pickup
Curve Shape: ANSI Extremely/Very/Moderately/Normally Inverse;
Definite Time (0.1 s base curve);
IEC Curve A/B/C and Short;
FlexCurve™ A/B/C (programmable curves);
IAC Extreme/Very/Inverse/Short
Curve Multiplier Time Dial: 0.5 to 30 for ANSI, IAC & FlexCurves™ in steps of 0.1 s;
0.05 to 100.00 for IEC curves in steps of 0.01
Reset Type: Instantaneous or Linear
Level Accuracy: Per current input
Timing Accuracy: at ≥ 1.03 × pickup: ± 3% of trip time or ± 20 ms (whichever is greater)
PHASE / NEUTRAL / GROUND / NEGATIVE SEQUENCE INSTANTANEOUS OVERCURRENT
Pickup Level: 0.05 to 20.00 in steps of 0.01 × CT
Dropout Level: 97 to 98% of Pickup
Time Delay: 0 to 60000 in steps of 1 ms
Level Accuracy: Per current input
Operate Time: Solid State Output: at 1.2 × pickup: 22 to 30 ms
at 2.0 × pickup: 18 to 26 ms
at 4.0 × pickup: 11 to 19 ms
Relay Outputs 2-5: at 1.2 × pickup: 28 to 36 ms
at 2.0 × pickup: 24 to 32 ms
at 4.0 × pickup: 17 to 25 ms
UNDERFREQUENCY (2 ELEMENTS)
Operating Current Pickup: 0.05 to 1.00 in steps of 0.01 × CT
Operating Voltage Pickup 0.10 to 0.99 in steps of 0.01 × VT
Pickup Level: 45.00 to 59.99 in steps of 0.01 Hz
Dropout Level: Pickup + 0.03 Hz
Time Delay: 0.00 to 600.00 s in steps of 0.01 s
Signal Source: Winding 1 phase A current / voltage
Level Accuracy: ±0.02 Hz
Operate Time: Solid State Output: at 3% beyond pickup: 120 to 150 ms
Relay Outputs 2 to 5: at 3% beyond pickup: 125 to 155 ms (delay set at 0.0 sec.)
FREQUENCY RATE OF CHANGE (4 ELEMENTS)
Operating Current Pickup: 0.05 to 1.00 in steps of 0.01 × CT
Operating Voltage Pickup 0.10 to 0.99 in steps of 0.01 × VT
Pickup Level: 45.00 to 59.99 in steps of 0.01 Hz
Dropout Level: Pickup + 0.03 Hz
Rate 1/2/3/4: 0.1 to 5.0 in steps of 0.1 Hz/sec.
Dropout Level: Pickup + 0.07 Hz/sec.
Signal Source: Winding 1 phase A current / voltage
Level Accuracy: ±0.02 Hz
Operate Time: The operate time of the frequency trend element is variable and is dependent on the decay
rate setting and the supervision frequency level.
