GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

8-24 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
4TH
HARMONIC
0300 Winding 1 Phase A 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0301 Winding 1 Phase B 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0302 Winding 1 Phase C 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0303 Winding 2 Phase A 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0304 Winding 2 Phase B 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0305 Winding 2 Phase C 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0306 Winding 3 Phase A 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0307 Winding 3 Phase B 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0308 Winding 3 Phase C 4th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0309 Reserved
↓↓ ↓ ↓↓↓ ↓
030F Reserved
5TH
HARMONIC
0310 Winding 1 Phase A 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0311 Winding 1 Phase B 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0312 Winding 1 Phase C 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0313 Winding 2 Phase A 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0314 Winding 2 Phase B 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0315 Winding 2 Phase C 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0316 Winding 3 Phase A 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0317 Winding 3 Phase B 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0318 Winding 3 Phase C 5th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0319 Reserved
↓↓ ↓ ↓↓↓ ↓
031F Reserved
6TH
HARMONIC
0320 Winding 1 Phase A 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0321 Winding 1 Phase B 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0322 Winding 1 Phase C 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0323 Winding 2 Phase A 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0324 Winding 2 Phase B 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0325 Winding 2 Phase C 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0326 Winding 3 Phase A 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0327 Winding 3 Phase B 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0328 Winding 3 Phase C 6th Harmonic Content 0.0 to 99.9 0.1 % ƒo F2 ---
0329 Reserved
↓↓ ↓ ↓↓↓ ↓
032F Reserved
Table 8–6: 745 MEMORY MAP (Sheet 8 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
