GE 745 TRANSFORMER MANAGEMENT RELAY

8-46 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
14DF Reserved
OUTPUT
RELAY 3
14E0 Output 3 Name (9 registers) --- --- --- F33 "Trip 2"
14E9 Output 3 Operation --- --- --- F66
0 = self-resetting
14EA Output 3 Type --- --- --- F38 0 = Trip
14EB Output 3 FlexLogic (20 registers) --- --- --- F47 ---
14FF Reserved
↓↓ ↓ ↓↓↓ ↓
150F Reserved
OUTPUT
RELAY 4
1510 Output 4 Name (9 registers) --- --- --- F33 Volts/Hertz Trip
1519 Output 4 Operation --- --- --- F66
0 = self-resetting
151A Output 4 Type --- --- --- F38 0 = Trip
151B Output 4 FlexLogic (20 registers) --- --- --- F47 ---
152F Reserved
↓↓ ↓ ↓↓↓ ↓
153F Reserved
OUTPUT
RELAY 5
1540 Output 5 Name (9 registers) --- --- --- F33 Overflux Alarm
1549 Output 5 Operation --- --- --- F66
0 = self-resetting
154A Output 5 Type --- --- --- F38 1 = Alarm
154B Output 5 FlexLogic (20 registers) --- --- --- F47 ---
155F Reserved
↓↓ ↓ ↓↓↓ ↓
156F Reserved
OUTPUT
RELAY 6
1570 Output 6 Name (9 registers) --- --- --- F33
Frequency Trip 1
1579 Output 6 Operation --- --- --- F66 0 = self-resetting
157A Output 6 Type --- --- --- F38 0 = Trip
157B Output 6 FlexLogic (20 registers) --- --- --- F47 ---
158F Reserved
↓↓ ↓ ↓↓↓ ↓
159F Reserved
OUTPUT
RELAY 7
15A0 Output 7 Name (9 registers) --- --- --- F33 Frequency Trip 2
15A9 Output 7 Operation --- --- --- F66 0 = self-resetting
15AA Output 7 Type --- --- --- F38 0 = Trip
15AB Output 7 FlexLogic (20 registers) --- --- --- F47 ---
15BF Reserved
↓↓ ↓ ↓↓↓ ↓
15CF Reserved
Table 8–6: 745 MEMORY MAP (Sheet 30 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
