8-58 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
WINDING 3
RESTD GND
FAULT
2210 Winding 3 Restricted Ground Fault Function --- --- --- F30 0 = Disabled
2211 Winding 3 Restricted Ground Fault Target --- --- --- F46 1 = Latched
2212 Winding 3 Restricted Ground Fault Pickup 0.05 to 20.00 0.01
×
CT F3 8 = 0.08
×
CT
2213 Winding 3 Restricted Ground Fault Slope 0 to 100 1 % F1 10%
2214 Winding 3 Restricted Ground Fault Delay 0.00 to 600.00 0.01 s F3 10 = 0.10 s
2215 Winding 3 Restricted Ground Fault Block --- --- --- F87 0 = Disabled
2216 Reserved
↓↓ ↓ ↓↓↓ ↓
221F Reserved
WINDING 1
RESTD GND
TREND
2220 Winding 1 Restricted Ground Trend Function --- --- --- F30 0 = Disabled
2221 Winding 1 Restricted Ground Trend Target --- --- --- F46 1 = Latched
2222 Winding 1 Restricted Ground Trend Pickup 0.05 to 20.00 0.01
×
CT F3 8 = 0.08
×
CT
2223 Winding 1 Restricted Ground Trend Slope 0 to 100 1 % F1 90%
2224 Winding 1 Restricted Ground Trend Delay 0.00 to 600.00 0.01 s F3 10 = 0.10 s
2225 Winding 1 Restricted Ground Trend Block --- --- --- F87 0 = Disabled
2226 Reserved
↓↓ ↓ ↓↓↓ ↓
222F Reserved
WINDING 2
RESTD GND
TREND
2230 Winding 2 Restricted Ground Trend Function --- --- --- F30 0 = Disabled
2231 Winding 2 Restricted Ground Trend Target --- --- --- F46 1 = Latched
2232 Winding 2 Restricted Ground Trend Pickup 0.05 to 20.00 0.01
×
CT F3 8 = 0.08
×
CT
2233 Winding 2 Restricted Ground Trend Slope 0 to 100 1 % F1 90%
2234 Winding 2 Restricted Ground Trend Delay 0.00 to 600.00 0.01 s F3 10 = 0.10 s
2235 Winding 2 Restricted Ground Trend Block --- --- --- F87 0 = Disabled
2236 Reserved
↓↓ ↓ ↓↓↓ ↓
223F Reserved
WINDING 3
RESTD GND
TREND
2240 Winding 3 Restricted Ground Trend Function --- --- --- F30 0 = Disabled
2241 Winding 3 Restricted Ground Trend Target --- --- --- F46 1 = Latched
2242 Winding 3 Restricted Ground Trend Pickup 0.05 to 20.00 0.01
×
CT F3 8 = 0.08
×
CT
2243 Winding 3 Restricted Ground Trend Slope 0 to 100 1 % F1 90%
2244 Winding 3 Restricted Ground Trend Delay 0.00 to 600.00 0.01 s F3 10 = 0.10 s
2245 Winding 3 Restricted Ground Trend Block --- --- --- F87 0 = Disabled
2246 Reserved
↓↓ ↓ ↓↓↓ ↓
224F Reserved
Table 8–6: 745 MEMORY MAP (Sheet 42 of 57)
