8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
VOLTS-PER-
HERTZ 1
continued
2303 Volts-Per-Hertz 1 Pickup 1.00 to 4.00 0.01 V/Hz F3 236 = 2.36 V/Hz
2304 Volts-Per-Hertz 1 Shape --- --- --- F86 0 = Def. Time
2305 Volts-Per-Hertz 1 Delay 0.00 to 600.00 0.01 s F3 200 = 2.00 s
2306 Volts-Per-Hertz 1 Reset 0.0 to 6000.0 0.1 s F2 0.0 s
2307 Volts-Per-Hertz 1 Block --- --- --- F87 0 = Disabled
2308 Reserved
↓↓ ↓ ↓↓↓ ↓
230F Reserved
VOLTS-PER-
HERTZ 2
2310 Volts-Per-Hertz 2 Function --- --- --- F30 0 = Disabled
2311 Volts-Per-Hertz 2 Target --- --- --- F46 1 = Latched
2312 Volts-Per-Hertz 2 Min. Operating Voltage 0.10 to 0.99 0.01 x VT F3 10 = 0.10 x VT
2313 Volts-Per-Hertz 2 Pickup 1.00 to 4.00 0.01 V/Hz F3
214 = 2.14 V/Hz
2314 Volts-Per-Hertz 2 Shape --- --- --- F86 0 = Def. Time
2315 Volts-Per-Hertz 2 Delay 0.00 to 600.00 0.01 s F3
4500 = 45.00 s
2316 Volts-Per-Hertz 2 Reset 0.0 to 6000.0 0.1 s F2 0.0 s
2317 Volts-Per-Hertz 2 Block --- --- --- F87 0 = Disabled
2318 Reserved
↓↓ ↓ ↓↓↓ ↓
231F Reserved
WINDING 1
THD LEVEL
2320 Winding 1 THD Level Function --- --- --- F30 0 = Disabled
2321 Winding 1 THD Level Target --- --- --- F46 0 = Self-reset
2322 Winding 1 THD Level Min. Operating Current 0.03 to 1.00 0.01
×
CT F3 10 = 0.10
×
CT
2323 Winding 1 THD Level Pickup 0.1 to 50.0 0.1 % ƒo F2 500 = 50.0%
2324 Winding 1 THD Level Delay 0 to 60000 1 s F1 10 s
2325 Winding 1 THD Level Block --- --- --- F87 0 = Disabled
2326 Reserved
↓↓ ↓ ↓↓↓ ↓
232F Reserved
WINDING 2
THD LEVEL
2330 Winding 2 THD Level Function --- --- --- F30 0 = Disabled
2331 Winding 2 THD Level Target --- --- --- F46 0 = Self-reset
2332 Winding 2 THD Level Min. Operating Current 0.03 to 1.00 0.01
×
CT F3 10 = 0.10
×
CT
2333 Winding 2 THD Level Pickup 0.1 to 50.0 0.1 % ƒo F2 500 = 50.0%
2334 Winding 2 THD Level Delay 0 to 60000 1 s F1 10 s
2335 Winding 2 THD Level Block --- --- --- F87 0 = Disabled
2336 Reserved
↓↓ ↓ ↓↓↓ ↓
233F Reserved
Table 8–6: 745 MEMORY MAP (Sheet 46 of 57)
GROUP ADDR
(HEX)
DESCRIPTION RANGE STEP
VALUE
UNITS FORMAT
CODE
FACTORY
DEFAULT
