GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

8-78 745 Transformer Management Relay GE Power Management
8.3 MODBUS MEMORY MAP 8 COMMUNICATIONS
8
0000 0000 0000 0101 5 = Y/d210°
0000 0000 0000 0110 6 = Y/d330°
0000 0000 0000 0111 7 = D/d0°
0000 0000 0000 1000 8 = D/d60°
0000 0000 0000 1001 9 = D/d120°
0000 0000 0000 1010 10 = D/d180°
0000 0000 0000 1011 11 = D/d240°
0000 0000 0000 1100 12 = D/d300°
0000 0000 0000 1101 13 = D/y30°
0000 0000 0000 1110 14 = D/y150°
0000 0000 0000 1111 15 = D/y210°
0000 0000 0001 0000 16 = D/y330°
0000 0000 0001 0001 17 = Y/z30°
0000 0000 0001 0010 18 = Y/z150°
0000 0000 0001 0011 19 = Y/z210°
0000 0000 0001 0100 20 = Y/z330°
0000 0000 0001 0101 21 = D/z0°
0000 0000 0001 0110 22 = D/z60°
0000 0000 0001 0111 23 = D/z120°
0000 0000 0001 1000 24 = D/z180°
0000 0000 0001 1001 25 = D/z240°
0000 0000 0001 1010 26 = D/z300°
0000 0000 0001 1011 27 = 3W (extn correction)
0000 0000 0001 1100 28 = Y/y0°/d30°
0000 0000 0001 1101 29 = Y/y0°/d150°
0000 0000 0001 1110 30 = Y/y0°/d210°
0000 0000 0001 1111 31 = Y/y0°/d330°
0000 0000 0010 0000 32 = Y/y180°/d30°
0000 0000 0010 0001 33 = Y/y180°/d150°
0000 0000 0010 0010 34 = Y/y180°/d210°
0000 0000 0010 0011 35 = Y/y180°/d330°
0000 0000 0010 0100 36 = Y/d30°/y0°
0000 0000 0010 0101 37 = Y/d30°/y180°
0000 0000 0010 0110 38 = Y/d30°/d30°
0000 0000 0010 0111 39 = Y/d30°/d150°
0000 0000 0010 1000 40 = Y/d30°/d210°
0000 0000 0010 1001 41 = Y/d30°/d330°
0000 0000 0010 1010 42 = Y/d150°/y0°
0000 0000 0010 1011 43 = Y/d150°/y180°
0000 0000 0010 1100 44 = Y/d150°/d30°
Table 8–7: 745 DATA FORMATS (Sheet 9 of 35)
FORMAT
CODE
APPLICABLE BITS DEFINITION
0000 0000 0010 1101 45 = Y/d150°/d150°
0000 0000 0010 1110 46 = Y/d150°/d210°
0000 0000 0010 1111 47 = Y/d150°/d330°
0000 0000 0011 0000 48 = Y/d210°/y0°
0000 0000 0011 0001 49 = Y/d210°/y180°
0000 0000 0011 0010 50 = Y/d210°/d30°
0000 0000 0011 0011 51 = Y/d210°/d150°
0000 0000 0011 0100 52 = Y/d210°/d210°
0000 0000 0011 0101 53 = Y/d210°/d330°
0000 0000 0011 0110 54 = Y/d330°/y0°
0000 0000 0011 0111 55 = Y/d330°/y180°
0000 0000 0011 1000 56 = Y/d330°/d30°
0000 0000 0011 1001 57 = Y/d330°/d150°
0000 0000 0011 1010 58 = Y/d330°/d210°
0000 0000 0011 1011 59 = Y/d330°/d330°
0000 0000 0011 1100 60 = D/d0°/d0°
0000 0000 0011 1101 61 = D/d0°/d60°
0000 0000 0011 1110 62 = D/d0°/d120°
0000 0000 0011 1111 63 = D/d0°/d180°
0000 0000 0100 0000 64 = D/d0°/d240°
0000 0000 0100 0001 65 = D/d0°/d300°
0000 0000 0100 0010 66 = D/d0°/y30°
0000 0000 0100 0011 67 = D/d0°/y150°
0000 0000 0100 0100 68 = D/d0°/y210°
0000 0000 0100 0101 69 = D/d0°/y330°
0000 0000 0100 0110 70 = D/d60°/d0°
0000 0000 0100 0111 71 = D/d60°/d60°
0000 0000 0100 1000 72 = D/d60°/d240°
0000 0000 0100 1001 73 = D/d60°/y30°
0000 0000 0100 1010 74 = D/d60°/y210°
0000 0000 0100 1011 75 = D/d120°/d0°
0000 0000 0100 1100 76 = D/d120°/d120°
0000 0000 0100 1101 77 = D/d120°/d180°
0000 0000 0100 1110 78 = D/d120°/y150°
0000 0000 0100 1111 79 = D/d120°/y330°
0000 0000 0101 0000 80 = D/d180°/d0°
0000 0000 0101 0001 81 = D/d180°/d120°
0000 0000 0101 0010 82 = D/d180°/d180°
0000 0000 0101 0011 83 = D/d180°/d300°
0000 0000 0101 0100 84 = D/d180°/y150°
Table 8–7: 745 DATA FORMATS (Sheet 10 of 35)
FORMAT
CODE
APPLICABLE BITS DEFINITION
