GE 745 TRANSFORMER MANAGEMENT RELAY User Manual

GE Power Management 745 Transformer Management Relay 11-1
11 SETPOINT TABLES 11.1 COMMISSIONING SUMMARY
11
11 SETPOINT TABLES 11.1 COMMISSIONING SUMMARY 11.1.1 S1 745 SETUP
Table 11–1: SETPOINTS PAGE 1 – 745 SETUP
DESCRIPTION DEFAULT USER VALUE
PREFERENCES
Beeper Enabled
Flash Message Time 4.0 s
Default Message Timeout 300 s
Default Message Intensity 25 %
COMMUNICATIONS
Slave Address 254
COM1 Baud Rate 19200 Baud
COM1 Parity None
COM1 Hardware RS485
COM2 Baud Rate 19200 Baud
COM2 Parity None
Front Baud Rate 19200 Baud
Front Parity None
DNP COMMUNICATIONS
DNP port None
DNP Point Mapping Enabled
Transmission delay 0 ms
Data Link Confirm Never
Data Link Confirm Timeout 1000 ms
Data Link Confirm Retries 3
Select/Operate Arm Timeout 10000 ms
Write Time Interval 0 min
Cold Restart Inhibit Disabled
RESETTING
Local Reset Block Disabled
Remote Reset Signal Disabled
CLOCK
IRIG-B Signal Type None
