11-18 745 Transformer Management Relay GE Power Management
11.1 COMMISSIONING SUMMARY 11 SETPOINT TABLES
11
11.1.6 S5 OUTPUTS
Table 11–7: S5 OUTPUTS (Sheet 1 of 5)
DESCRIPTION DEFAULT USER VALUE DESCRIPTION DEFAULT USER VALUE
OUTPUT 1 OUTPUT 2
Name Solid State Trip Name “Trip 1”
Operation Self-resetting Operation Self-resetting
Type Trip Type Trip
FlexLogic 01 Percent Diff OP FlexLogic 01 Percent Diff OP
FlexLogic 02 Inst Diff OP FlexLogic 02 Inst Diff OP
FlexLogic 03 Any W1 OC OP FlexLogic 03 Any W1 OC OP
FlexLogic 04 Any W2 OC OP FlexLogic 04 Any W2 OC OP
FlexLogic 05 OR (4 inputs) FlexLogic 05 OR (4 inputs)
FlexLogic 06 FlexLogic 06
FlexLogic 07 FlexLogic 07
FlexLogic 08 FlexLogic 08
FlexLogic 09 FlexLogic 09
FlexLogic 10 FlexLogic 10
FlexLogic 11 FlexLogic 11
FlexLogic 12 FlexLogic 12
FlexLogic 13 FlexLogic 13
FlexLogic 14 FlexLogic 14
FlexLogic 15 FlexLogic 15
FlexLogic 16 FlexLogic 16
FlexLogic 17 FlexLogic 17
FlexLogic 18 FlexLogic 18
FlexLogic 19 FlexLogic 19
FlexLogic 20 FlexLogic 20
