4-17
6. Remove main and safety cables from counterweight assembly by dislodging ball
ends of cables from retaining notch in counterweight.
7. Remove bottom follower cable retainer clip from counterweight assembly by reĆ
moving two slotted hex washer head capscrews.
8. Remove follower cable form counterweight assembly by dislodging ball end of caĆ
ble from retaining notch in counterweight.
Install Counterweight
1. Replace main and safety cables in counterweight assembly by inserting ball ends
of cables into retaining notch in top of counterweight. See Illustration 4-9.
2. Replace cable retainer clip in top of counterweight assembly and secure with two
slotted hex washer capscrews.
3. Place follower cable ball end into retaining notch in bottom of counterweight.
The follower cable must be installed on the right side
to function properly.
4. Replace follower cable retainer clip in bottom of counterweight assembly and seĆ
cure with two slotted hex washer head capscrews.
5. Slide follower cable down inside of vertical column as far as possible.
6. Slide counterweight assembly into vertical column.
7. Check counterweight balancing. Refer to Section 10.
