6-5
1 %,")(($"- !(# $')/$ !--$+0 $,-
$+'%(!&-+%*
1. Disconnect sense leads from J5 and J6 on left side of battery test terminal strip,
and J1, J2, J3 and J4 from right side.
2. Remove battery test terminal strip from battery compartment.
1 )(-%(.$ !--$+0 %,")(($"-%)($')/!&
1. Disconnect Cable #8 from Battery #5 (+) and slide boot over cable terminal.
2. Disconnect Cable #3 from Battery #6 (-) and slide boot over cable terminal.
3. Disconnect remaining Cable #1 from Battery #6(+) and Battery #5 (-) and
slide boot over each cable terminal.
4. Remove Batteries #5 and #6 and the separator pad between them.
5. Remove Insulator #5, #6, and Insulator #2 behind Batteries #5 and #6.
6. Disconnect Cable #4 from Terminal #4 of circuit breaker in AMX1 A3 and slide
boot over cable terminal. Disconnect other end of Cable #4 from Battery #1 (+)
and slide boot over cable terminal.
7. Disconnect Cable #8 from Battery #4 (-) and slide boot over cable terminal.
8. Disconnect one of the Cable #7s from Battery #1 (-) and Battery #2 (+) and
slide a boot over each cable terminal.
9. Disconnect the other Cable #7 from Battery #3 (-) and Battery #4 (+) and
slide a boot over each cable terminal.
10. Disconnect Cable #6 from Battery #2 (-) and Battery #3 (+) and slide a boot
over each cable terminal.
11. Remove Insulator #4 and the two remaining Insulator #2s.
12. Remove the four remaining batteries and battery separator pads.
1 (,-!&& !--$+%$,
 
       
       
       
      
During installation:
D Make all battery connections as shown in Illustration 6-3 using the hardĆ
ware shown.
D Reference to the right and left sides of battery compartment are relative to
the view shown in Illustration 4.

