27 ZONES 9-16, CONFIGURATION GROUPS
6-6-6-6-6-6-6-6
ZONES 9-16, PARTITION SELECTION (Segment 1=Zone 9 thru Segment 8=Zone 16)
Segments 1 2 3 4 5 6 7 8
Partition 1 1 1 1 1 1 1 1 1
Partition 2 2 2 2 2 2 2 2 2
Partition 3 3 3 3 3 3 3 3 3
28
Partition 4 4 4 4 4 4 4 4 4
29 ZONES 17-24, CONFIGURATION GROUPS
6-6-6-6-6-6-6-6
ZONES 17-24, PARTITION SELECTION (Segment 1=Zone 17 thru Segment 8=Zone 24)
Segments 1 2 3 4 5 6 7 8
Partition 1 1 1 1 1 1 1 1 1
Partition 2 2 2 2 2 2 2 2 2
Partition 3 3 3 3 3 3 3 3 3
30
Partition 4 4 4 4 4 4 4 4 4
31 ZONES 25-32, CONFIGURATION GROUPS
6-6-6-6-6-6-6-6
ZONES 25-32, PARTITION SELECTION (Segment 1=Zone 25 thru Segment 8=Zone 32)
Segments 1 2 3 4 5 6 7 8
Partition 1 1 1 1 1 1 1 1 1
Partition 2 2 2 2 2 2 2 2 2
Partition 3 3 3 3 3 3 3 3 3
32
Partition 4 4 4 4 4 4 4 4 4
33 ZONES 33-40, CONFIGURATION GROUPS
6-6-6-6-6-6-6-6
ZONES 33-40, PARTITION SELECTION (Segment 1=Zone 33 thru Segment 8=Zone 40)
Segments 1 2 3 4 5 6 7 8
Partition 1 1 1 1 1 1 1 1 1
Partition 2 2 2 2 2 2 2 2 2
Partition 3 3 3 3 3 3 3 3 3
34
Partition 4 4 4 4 4 4 4 4 4
35 ZONES 41-48, CONFIGURATION GROUPS
6-6-6-6-6-6-6-6
ZONES 41-48, PARTITION SELECTION (Segment 1=Zone 41 thru Segment 8=Zone 48)
Segments 1 2 3 4 5 6 7 8
Partition 1 1 1 1 1 1 1 1 1
Partition 2 2 2 2 2 2 2 2 2
Partition 3 3 3 3 3 3 3 3 3
36
Partition 4 4 4 4 4 4 4 4 4
SIREN AND SYSTEM SUPERVISION
Segment 1 (Circle Numbers To Program)
1 Siren sounds for telephone line cut while armed (BELL output and wireless sirens)
2 Siren sounds for telephone line cut while disarmed (BELL output and wireless sirens)
3 Siren blast at arming (pulse) (BELL output: YES; wireless sirens: NO)
4 Siren blast at exit delay expiration (pulse) (BELL output: YES; wireless sirens: NO)
5 Siren blast at closing kissoff (pulse)
6 Siren sounds during a cross zone verification time
7 Siren sounds for a tamper
8 Siren blast once for keyswitch arming, twice for disarming (BELL output: YES; wireless sirens: NO)
Segment 2 (Circle Numbers To Program)
1 Convert siren driver to voltage out
2 Siren sounds for expander trouble (BELL output: YES; wireless sirens: NO)
3 Zones to always restore
37
4 Dynamic battery test performed upon arming
