NetworX Version 3 Installation Manual
185
Term Definition
Receiver Features A menu entry that groups programmable options for RF receivers.
Reset Settings A menu option that defaults the selected receiver to factory defaults.
RF Keypads
A menu entry that displays the RSSI value for the selected wireless keypad.
RF Receiver 32 A menu entry that groups all options for the selected RF receiver. The
integrated NetworX V3 RF receiver has ID 32.
RF Sensors A menu entry that displays the RSSI value for the selected wireless zone.
RF Sirens/IO A menu entry that displays the RSSI value for the selected wireless siren or IO
module.
RSSI RF Device A menu entry that groups entries related to measuring RF signal strengths.
Sequential Programming A menu option that allows a group of RF sensors to be enrolled in sequence.
Once the first sensor (Start Learning sensor) is configured, the detectors are
learned-in in sequence. The value of ‘Start Learning’ is increased automatically.
This option allows easier programming.
Short Window A menu option that specifies the short supervision window for RF devices. RF
devices on 868 MHz typically report every 15 minutes. Depending on the
country regulations, this timer must be set to specific values.
Sirens/IO Features A menu entry that groups troubleshooting options for IO modules.
Smoke A menu entry that groups smoke sensor options.
Start Zone A menu option that specifies the first zone number of zones on the RF receiver.
Note: In case of the RF Receiver 32 (the NetworX V3 built-in 868MHz Gen2
receiver), this option is not visible. In the NetworX V3 system, you can set this
value for additional RF receivers only. For the receiver 32 the starting zone is
always zone 1.
Supervised A menu option that enables supervision of the selected RF sensor.
Supervision A menu entry that groups wireless supervision options.
Switch to EN A menu option that switches the RF receiver to the EN 50131-compatible
settings. For additional information about the EN 50131 norm, see Appendix 7.
System ID A menu entry that allows to set the SysID value. System ID is a 3 digit code
which should be unique for the panel.
Tamper A menu option that enables/disables the tamper of a smoke sensor.
Threshold A menu entry that allows to set the Low Battery threshold and the Low Aux
Voltage threshold for the particular IO module/siren.
Time Selects the amount of time an output will remain activated when an output
triggers. If this location is programmed as a zero, the output will follow the
particular event (latched).
