NetworX Version 3 Installation Manual
190
LOCATIONS 150-159 - AUTHORIZING USERS 1 - 99 TO TRIGGER OUTPUTS 1 - 8 (10 segments,
feature selection data)
When activating outputs with a user code (event 45), locations 150-159 can be used to restrict certain
codes from activating certain outputs. Each location contains 10 segments. Segment 1 corresponds to
user 1, segment 10 corresponds to user 10. The LED’s correspond to outputs 1 - 8.
Location Segments Type Function
150 10 option
AUTHORIZING USERS 1 - 10 TO TRIGGER OUTPUTS 1 – 8
Segment 1 – user 1, segment 2 – user 2 ….. segment 10 – user 10
151 10 option
AUTHORIZING USERS 11 - 20 TO TRIGGER OUTPUTS 1 – 8
Segment 1 – user 11, segment 2 – user 12 ….. segment 10 – user 20
152 10 option AUTHORIZING USERS 21 - 30 TO TRIGGER OUTPUTS 1 - 8
153 10 option AUTHORIZING USERS 31 - 40 TO TRIGGER OUTPUTS 1 - 8
154 10 option AUTHORIZING USERS 41 - 50 TO TRIGGER OUTPUTS 1 - 8
155 10 option AUTHORIZING USERS 51 - 60 TO TRIGGER OUTPUTS 1 - 8
156 10 option AUTHORIZING USERS 61 - 70 TO TRIGGER OUTPUTS 1 - 8
157 10 option AUTHORIZING USERS 71 - 80 TO TRIGGER OUTPUTS 1 - 8
158 10 option AUTHORIZING USERS 81 - 90 TO TRIGGER OUTPUTS 1 - 8
159 10 option AUTHORIZING USERS 91 - 99 TO TRIGGER OUTPUTS 1 - 8
Option Function
ON Code will activate Output 1 1
OFF Code will NOT activate output 1
ON Code will activate Output 2 2
OFF Code will NOT activate output 2
ON Code will activate Output 3 3
OFF Code will NOT activate output 3
ON Code will activate Output 4 4
OFF Code will NOT activate output 4
ON Code will activate Output 5 5
OFF Code will NOT activate output 5
ON Code will activate Output 6 6
OFF Code will NOT activate output 6
ON Code will activate Output 7 7
OFF Code will NOT activate output 7
ON Code will activate Output 8 8
OFF Code will NOT activate output 8
