GE RAFT VOLUSON™ P8/VOLUSON™P6
DIRECTION 5775469, R
EVISION 3 DRAFT (JULY 19, 2018) BASIC SERVICE MANUAL
6-4 Section 6-4 - Modification of Keyboard Layout
NOTE: If the desired language is not listed, click the ADD button, choose the desired input language from the
drop down menu, as shown in Figure 6-2 below, and then confirm with OK.
8.) If not already done, select the default input language from the drop down menu (see: Figure 6-1).
The corresponding keyboard layout is changed automatically.
9.) Click on APPLY
and then close the window with OK.
10.)Close the Service page with the SAVE & EXIT
and restart the system.
11.)Reenter “Keyboard Layout” by repeating step 1.) to step 6.). This time remove unused language(s)
12.)Test the Keyboard function:
- Press the ABC key on the control panel.
- Press some keys on the keyboard and verify the entered text.
Figure 6-2 add input language
