GEM WK6 User Manual

○○○○○○○○○○○○○○○○○○○○○○
System Exclusive A•35
xx 18 06 00 00 01 00 7F vol_group_B Volume sent of eff. group B
xx 18 07 00 00 01 00 3E pan -31 -> +31 3EH =31
xx 18 08 00 00 01 00 07 rand_pitch 0
xx 18 09 00 00 01 00 07 rand_pan 0
xx 18 0A 00 00 01 01 0B Harmony 1 -> 11 1
xx 18 0B 00 00 01 00 0C PitchRange 0 -> 12 0
MIDI IN FILTER ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 19 00 00 00 01 00 64 filter_in1 0 -> 100 00H
xx 19 01 00 00 01 00 64 filter_in2 0 -> 100 00H
xx 19 02 00 00 01 00 64 filter_in3 0 -> 100 00H
xx 19 03 00 00 01 00 64 filter_in4 0 -> 100 00H
xx 19 04 00 00 01 00 64 filter_in5 0 -> 100 00H
xx 19 05 00 00 01 00 64 filter_in6 0 -> 100 00H
xx 19 06 00 00 01 00 64 filter_in7 0 -> 100 00H
MIDI OUT FILTER ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 1A 00 00 00 01 00 64 filter_out1 0 -> 100 00H
xx 1A 01 00 00 01 00 64 filter_out2 0 -> 100 00H
xx 1A 02 00 00 01 00 64 filter_out3 0 -> 100 00H
xx 1A 03 00 00 01 00 64 filter_out4 0 -> 100 00H
xx 1A 04 00 00 01 00 64 filter_out5 0 -> 100 00H
xx 1A 05 00 00 01 00 64 filter_out6 0 -> 100 00H
xx 1A 06 00 00 01 00 64 filter_out7 0 -> 100 00H
LOCAL ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 1B 00 00 00 01 00 01 ped_ftsw[1]
xx 1B 01 00 00 01 00 01 ped_ftsw[2]
xx 1B 02 00 00 01 00 01 ped_ftsw[3]
SLIDER ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 1C 00 00 00 01 00 7F Attack -64 +63 40H = 0
xx 1C 01 00 00 01 00 7F Release -64 +63 40H = 0
xx 1C 02 00 00 01 00 7F Flt Cutoff -64 +63 40H = 0
xx 1C 03 00 00 01 00 7F Flt Resonance -64 +63 40H = 0
xx 1C 04 00 00 01 00 7F Decay -64 +63 40H = 0
xx 1C 05 00 00 01 00 7F LFO Depth -64 +63 40H = 0
xx 1C 06 00 00 01 00 7F LFO Rate -64 +63 40H = 0
xx 1C 07 00 00 01 00 7F LFO Delay -64 +63 40H = 0
xx 1C 08 00 00 02 0: 7F+0:F Soundnr Prog.Change(MSB) + Bank(LSB) 0
DRUM KIT EDITING
LAYER1 SOUND PATCH ( xx = NOTE = 0 - 7F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 1D 00 00 00 02 0: 7F+0:F Soundnr Prog.Change(MSB) + Bank(LSB)
xx 1D 01 00 00 01 00 7F Level 00 127
xx 1D 02 00 00 01 00 7F Panorama -64 +63
xx 1D 03 00 00 01 00 7F Transpose -64 +63
xx 1D 04 00 00 01 00 7F Tune -64 +63
xx 1D 05 00 00 01 00 7F FltCutOff -64 +63
xx 1D 06 00 00 01 00 03 Exclude 00 03
xx 1D 07 00 00 01 00 7F Effect 1 00 127
xx 1D 08 00 00 01 00 7F Effect 2 00 127
xx 1D 09 00 00 01 00 04 Analog Out 00 04
