2•12 User Guide
PLAY WITH THE PEDALS
The rear connections panel includes four jacks
for control pedals, denoted Volume, 1, 2, Damper.
The Volume jack is a non-programmable port for
a standard Volume Pedal (optional). The remain-
ing three pedal jacks are programmable and pre-
set to provide Performance functions.
The default configuration of the pedals is as fol-
lows:
• Ped1 = Soft
• Ped2 = Sostenuto
• Ped3 = Damper (sustain)
• Volume = Volume
The pedal jacks 1, 2 and Damper are function
assignable and can be independently enabled or
disabled to react with the keyboard tracks of a
Performance.
All three pedals (1, 2, Damper) can be pro-
grammed to accept Switch action (on/off) or Con-
tinuous (graduated levels) control pedals (Volume
type).
PLAY WITH THE WHEELS
The on-board controlling devices include two
wheels on the left key block, both preset for Per-
formance functions.
The default configuration of the wheels is as fol-
lows:
• Wheel 1 (left) = Pitch Bend
• Wheel 2 (right) = Modulation
Wheel 1 is spring loaded to return to the central
position.
Wheel 2 is centre-dented in order to be able to
take it exactly at the central position.
The Wheels can be enabled or disabled to react
with the keyboard tracks of a Performance.
