2•62 User Guide
THE MIDI CONFIGURATION
Each track of a Performance can be independ-
ently configured with regards to how the track
handles keyboard data, MIDI IN and MIDI OUT
data and the information directed to the internal
sound engine. Each parameter (MIDI IN, MIDI
OUT, Keyboard and Sound Engine) can be inde-
pendently enabled/disabled for the track selected.
How to configure a track
1. After entering Edit MIDI, press the soft button
F2 (or the page button) to open the Configura-
tion page.
The display shows the current configuration
of the first 8 tracks of the current Perform-
ance.
2. Select the track whose configuration you wish to
change using the corresponding Soft button.
Use the Track Scroll buttons, or the /
cursor buttons to bring other tracks into view.
3. Select the parameter to enable/disable with the
cursor arrow.
The first parameter represents the assigned
MIDI IN port (A or B), then the keyboard fol-
lowed by the internal sound engine and OUT
port.
4 Rotate the DIAL to disable or enable the selected
parameter.
For example, if you set the MIDI IN port to
OFF, the track cannot receive MIDI IN data.
Or, if you set the keyboard to off, the track is
muted but still available for MIDI IN data. Or,
if you disable the sound engine, the track
cannot play the internal sounds but can play
external sounds via MIDI OUT. Finally, if yo
set the OUT port to off, the track cannot
trasmit data via MIDI OUT. The on/off com-
binations of the 4 available elements provide
endless MIDI configurations.
Repeat the procedure for other parameters
and other tracks.
