GEM WK6 User Manual

○○○○○○○○○○○○○○○○○○○○○○
Display 1•3
THE DISPLAY
The SK760/880 display is the principal user interface which communicates the status of the instrument
at all times.
TRACK
SCROLL
A
B
C
D
E
F
G
H
F8
F7
F6
F5
F4
F3
F2
F1
SOFT BUTTONS A … H SOFT BUTTONS F1 … F8
TRACK SCROLL BUTTONS PAGE (MENU) SCROLL BUTTONS
ENTER
TEMPO
/DA
TA
ESCAPE
EFFECTS
MIDI
MIXER
EDIT
/ NUMBER
CNT
/ P
ADS
TRACKS
SOUND
ST
. / SONG
SYNTH
GENERAL
DEMO
PRELOAD
DISK
H. D.
1
2
3
4
5
6
7
8
9
0
+
_
NEGATIVE HIGHLIGHT
CURSOR
EDIT/NUMBER
SECTION
ENABLED FOR
NUMERIC ENTRY
WHEN THE
KEYPAD LED
IS ON
ENTER/ESCAPE
AND DIAL
CURSOR
ARROWS
O
LD
KEY
PAD
NAVIGATION, DATA ENTRY, CONFIRMA-
TION/CANCELLATION
The principal navigating controls are the CUR-
SOR ARROWS (directional arrows) and the prin-
cipal Data entry device is the DIAL. Secondary
navigating devices are the SOFT BUTTONS on
the left and right of the display, and the TRACK
SCROLL and PAGE (MENU) SCROLL buttons
above the Soft buttons. A secondary data entry
device is the numeric keypad (the EDIT/NUM-
BER section), which enters absolute numbers
when the KEYPAD LED is on.
The display’s cursor is a negative highlight zone
which can be moved by means of the cursor but-
tons. The selected parameter can be modified
with the DIAL or NUMERIC KEYPAD. Confirma-
tion or cancellation of an operation within the dis-
play is with the ENTER or ESCAPE buttons.
