A•34 Appendix
PERFORMANCE PARAMETERS
EFFECTS A
Address(H) Size (H) Range(H) Parameter Description Default
00 13 00 00 00 01 00 17 Eff_Type1 0 -> 23 5=St.Concert
00 13 01 00 00 01 00 7F eff_vol1 0 -> 127 5AH = 90
00 13 02 00 00 01 par#1_1
00 13 03 00 00 01 par#2_1
00 13 04 00 00 01 par#3_1
00 13 05 00 00 01 00 1F Eff_Type2 0 -> 31 9 = Chorus2
00 13 06 00 00 01 00 7F eff_vol2 0 -> 127 79H = 121
00 13 07 00 00 01 par#1_2
00 13 08 00 00 01 par#2_2
00 13 09 00 00 01 par#3_2
00 13 0A 00 00 01 00 7F Eff2ToEff1 0 -> 127 0
EFFECTS B
Address(H) Size (H) Range(H) Parameter Description Default
00 14 00 00 00 01 00 17 Eff_Type1 0 -> 23 2= Hall3
00 14 01 00 00 01 00 7F eff_vol1 0 -> 127 37H = 55
00 14 02 00 00 01 par#1_1
00 14 03 00 00 01 par#2_1
00 14 04 00 00 01 par#3_1
00 14 05 00 00 01 00 1F Eff_Type2 0 -> 31 0=MonoDelay1
00 14 06 00 00 01 00 7F eff_vol2 0 -> 127 79H = 121
00 14 07 00 00 01 par#1_2
00 14 08 00 00 01 par#2_2
00 14 09 00 00 01 par#3_2
00 14 0A 00 00 01 00 7F Eff2ToEff1 0 -> 127 0
TRACK SOUND ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 15 00 00 00 02 0: 7F+0:F Soundnr Prog.Change(MSB) + Bank(LSB)
xx 15 01 00 00 01 0 Ctrl32 no sound if no zero
0
MIDI CONFIGURATION ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 16 00 00 00 01 00 03 source Track source
4
xx 16 01 00 00 01 00 03 destination Track destination
5
xx 16 04 00 00 01 01 02 Midi_In_Port 1 = MidiIn A, 2= MidiIn B
xx 16 05 00 00 01 01 10 Midi_In-Ch 1->10 = channels 1->16
xx 16 06 00 00 01 01 02 Midi_Our_Port 1 = MidiOut A, 2= MidiOut B
xx 16 07 00 00 01 01 10 Midi_out-Ch 1->10 = channels 1->16
COMMON ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 17 00 00 00 01 00 7F volume
xx 17 01 00 00 01 00 78 transp -60 -> +60 3CH = 0
xx 17 02 00 00 02 00 0300 delay 0 -> 768 Use nibblized if > 127 0
xx 17 03 00 00 01 00 07 dyn_resp 0
xx 17 04 00 00 01 00 01 m_transp 1
INTERNAL ( xx = CHANNEL = 0 - 1F )
Address(H) Size (H) Range(H) Parameter Description Default
xx 18 00 00 00 01 00 02 mode 0
xx 18 01 00 00 01 00 01 m_priority Poly.Mono 0
xx 18 02 00 00 01 00 7F detune -64 -> +63 40H = 0
xx 18 03 00 00 01 00 03 analog_out 0
xx 18 04 00 00 01 00 01 effect_group Selection effects group A or B
xx 18 05 00 00 01 00 7F vol_group_A Volume sent of eff. group A
