Specification Desc./Quantity
Rear rim 14'' x 4.50
Front tyre Tubeless 120/70-12" 51S or 51P
Rear tyre Tubeless 140/70 - 14" 68S or 68P reinf
Front tyre pressure (with passenger) 1.6 bar (1.8 bar)
Rear tyre pressure (with passenger) 2.4 bar (2.6 bar)
Tightening Torques
STEERING
Name Torque in Nm
Steering lower ring nut (central headstock) 22 ÷ 27 loosen by 90°
Steering upper ring nut (central headstock) 27 ÷ 33
Handlebar fixing screw 50 ÷ 55
Fixing screws for handlebar control assembly U-
bolts
7 ÷ 10
CHASSIS
Name Torque in Nm
Swinging arm set screw bushing 5 ÷ 7
Engine arm bolt - frame arm 32.5 ÷ 40
Swinging arm set screw bushing nut 54 ÷ 60
Engine-swinging arm bolt 98 ÷ 118
Frame-swinging arm bolt 54 ÷ 60
Centre stand bolt 31 ÷ 39
FRONT SUSPENSION
Name Torque in Nm
Shock absorber lower clamp 19 ÷ 26
Upper shock absorber clamp 19 ÷ 29
Front wheel fixing screws 19 ÷ 24
Steering arm bolt nut 20 ÷ 25
Tilt calliper fixing screws 20 ÷ 25
Front wheel shaft 74 ÷ 88
Arm coupling screws 45 ÷ 50
Screws fixing arms to side headstocks 45 ÷ 50
Screws fixing arms to central headstock 45 ÷ 50
Screws fixing the half-arm coupling flange 20 ÷ 25
Fixing screws for tilt locking disc section 20 ÷ 25
Side headstock upper ring nut 20 - 24
Side headstock lower ring nut 12 ÷ 15
Screw fixing sliding stem to shock absorber 45 ÷ 50
Clamp for sliding stem locking device 6.5 ÷ 10.5
Fixing nuts for constant-velocity universal joints 18 ÷ 20
Potentiometer to anti-tilting device clamp 8 ÷ 10
Electric motor to anti-tilting device clamp 11 ÷ 13
Clamp fixing pump bolt to anti-tilting device 11 ÷ 13
Pump to anti-tilting device clamp 11 ÷ 13
Pressure switch to distribution frame 18 ÷ 20
Sensor to tilt gripper clamp 2.5 ÷ 2.9
Pipe terminals to fifth wheel check spring 7 ÷ 11
Joint to anti-tilting device pump 20 ÷ 25
Characteristics Fuoco 500 i.e.
CHAR - 6
